DE_Imagery_SP/DE_Imagery_2002 (ImageServer)

View In:   ArcGIS JavaScript   ArcGIS Online Map Viewer   ArcGIS Earth

Service Description:

Resolution: 0.25 Meter

Band: 3-band: G, R, NIR

EarthDataDelivered as 2010 tiles.Each tile is 1.7km x 1.7km, 6800x6800 pixels, and 135MB (TIF). SRS: NAD83 HARN Delaware State Plane metersScale: 1:2,400

This false color IR digital orthophotography, at a scale of 2,400, was produced for the State of Delaware for the purpose of statewide base mapping by EarthData International of Maryland, LLC.

Compliance with the accuracy standard was ensured by the placement of GPS ground control prior to the acquisition of aerial photography. The following checks were performed. 1. The ground control and airborne GPS data stream were validated through a fully analytical bundle aerotriangulation adjustment. The residuals of the adjustment met the required standards for accuracy which are 1 part in 10,000 of the flying height for the horizontal position (X and Y) and 1 part in 9,000 or better of the flying height in elevation (Z). 2. The DTM data was checked against the project control. The technician visited and confirmed the accuracy of the project mass points during initial compilation. 3. Digital orthophotography was validated through an inspection of edge matching and visual inspection for image quality

Aerial photography was acquired using a flight design that included a total of 1196 exposures in 20 North-South oriented flight line. Aerial photography was exposed on Kodak CIR film 1443, emulsion number 1133012. Aerial photography was supplemented with the simultaneous acquisition of airborne GPS data, which captured the ground coordinate for the nadir point of each photograph. Aerial photography was exposed at an altitude of 11,000' above mean terrain yielding an approximate scale of 1 / 21,600.



Name: DE_Imagery_SP/DE_Imagery_2002

Description:

Resolution: 0.25 Meter

Band: 3-band: G, R, NIR

EarthDataDelivered as 2010 tiles.Each tile is 1.7km x 1.7km, 6800x6800 pixels, and 135MB (TIF). SRS: NAD83 HARN Delaware State Plane metersScale: 1:2,400

This false color IR digital orthophotography, at a scale of 2,400, was produced for the State of Delaware for the purpose of statewide base mapping by EarthData International of Maryland, LLC.

Compliance with the accuracy standard was ensured by the placement of GPS ground control prior to the acquisition of aerial photography. The following checks were performed. 1. The ground control and airborne GPS data stream were validated through a fully analytical bundle aerotriangulation adjustment. The residuals of the adjustment met the required standards for accuracy which are 1 part in 10,000 of the flying height for the horizontal position (X and Y) and 1 part in 9,000 or better of the flying height in elevation (Z). 2. The DTM data was checked against the project control. The technician visited and confirmed the accuracy of the project mass points during initial compilation. 3. Digital orthophotography was validated through an inspection of edge matching and visual inspection for image quality

Aerial photography was acquired using a flight design that included a total of 1196 exposures in 20 North-South oriented flight line. Aerial photography was exposed on Kodak CIR film 1443, emulsion number 1133012. Aerial photography was supplemented with the simultaneous acquisition of airborne GPS data, which captured the ground coordinate for the nadir point of each photograph. Aerial photography was exposed at an altitude of 11,000' above mean terrain yielding an approximate scale of 1 / 21,600.



Single Fused Map Cache: true

Tile Info: Storage Info: Extent: Initial Extent: Full Extent: Pixel Size X: 0.25

Pixel Size Y: 0.25

Band Count: 3

Pixel Type: U8

RasterFunction Infos: {"rasterFunctionInfos": [{ "name": "None", "description": "A No-Op Function.", "help": "" }]}

Mensuration Capabilities: Basic

Has Histograms: true

Has Colormap: false

Has Multi Dimensions : false

Rendering Rule:

Min Scale: 8000000

Max Scale: 1000

Copyright Text: EarthData International of Maryland

Service Data Type: esriImageServiceDataTypeProcessed

Min Values: 0, 0, 0

Max Values: 255, 255, 255

Mean Values: 113.96005560260117, 105.7437771067119, 118.82646911055366

Standard Deviation Values: 56.185450293401516, 50.155083084720005, 49.36263452685784

Object ID Field: OBJECTID

Fields: Default Mosaic Method: ByAttribute

Allowed Mosaic Methods: ByAttribute,NorthWest,Center,LockRaster,Nadir,Viewpoint,Seamline,None

SortField: LowPS

SortValue: 0

Mosaic Operator: First

Default Compression Quality: 75

Default Resampling Method: Bilinear

Max Record Count: 1000

Max Image Height: 500000

Max Image Width: 500000

Max Download Image Count: 20

Max Mosaic Image Count: 2000

Allow Raster Function: true

Allow Copy: true

Allow Analysis: true

Allow Compute TiePoints: false

Supports Statistics: true

Supports Advanced Queries: true

Use StandardizedQueries: true

Raster Type Infos: Has Raster Attribute Table: false

Edit Fields Info: null

Ownership Based AccessControl For Rasters: null

Child Resources:   Info   Histograms   Statistics   Key Properties   Legend   Raster Function Infos

Supported Operations:   Export Image   Query   Identify   Measure   Compute Histograms   Compute Statistics Histograms   Get Samples   Compute Class Statistics   Query Boundary   Compute Pixel Location   Compute Angles   Validate   Project
